Nano LED Backlight Module

Description

Evolve Nano LED Backlit Sign Module

The Nano is the smallest and most versatile LED Module on the market and can provide a solution for the narrowest of channel letters and strokes. With 0.7W of power it can be used in all applications. The Nano is the proverbial "get out of jail" card for sign writers and installers as it will fit into the narrowest of channel letters with a depth of 30mm - 60mm without "spotting" due to its unique "Bat Wing Optical Lens". Internal constant current IC allows connection of up to 50 modules in series while maintaining perfect operating temperature.

Specifications

Evolve Nano LED Module Features:

Suitable for 30 - 60mm depth
160° Bat Wing Optical Lens
3 Step MacAdam colour binning
Constant current onboard technology
50 modules in series

Power Input	0.7W
Lumens	70lm
Colour Temp	6500k
Warranty	5 years
Dimensions	26.5 x 9 x 8.2mm
Series Connectivity	50 Modules

Frequently Asked Questions

What are LED modules used for?

Our LED modules are ideal for sign and channel letter illumination, backlighting, display cases and commercial lighting applications where compact, bright light sources are needed.

How are the modules mounted and wired?

Modules mount quickly with self-adhesive backing or screws and wire together in a chain back to a low-voltage power supply, making large installations straightforward.

Are they suitable for outdoor signage?

Many of our modules carry weather-resistant ratings for outdoor sign work - check the specification sheet, or contact us and we will confirm the right choice.

What power supply do they need?

Modules run on low-voltage constant-voltage power. We can help you select and size the correct driver for the number of modules in your sign or project.

Do you deliver the Nano LED Backlight Module New Zealand-wide?

Yes. Specialized Lighting Concepts dispatches the Nano LED Backlight Module nationwide from our Auckland warehouse. Freight is calculated at checkout, and you are welcome to contact us for a quote on larger or trade orders.

Need help with your layout?

Contact our expert sales team or use the LED System Designer on the website for more detailed layouts.

Contact our sales team LED System Designer Coming soon

Downloads

PDFNANO LED Sign Module specPDF, PDFSIGN ILLUMINATION SYSTEMSPDF,
